CNC Heavy Duty Milling Machine-CNC Series

Products List

  Travel
X-axis 800~1200/(31.5~47.2) mm/(inch)
Y-axis 900/(35.4) mm/(inch)
Z-axis 550/(21.6) mm/(inch)
Spindle nose to table surface 100~770/(3.9~30.3) mm/(inch)
Distance between columns 1000/39 mm/(inch)
Spindle speed (Built-in type) 18,000 rpm

FMC-B1V(L)


CNC milling machine specification
table size 1372 x 305 mm/(inch)
T-slot 16 x 3 mm/(inch)
Max. table load 500 kgs
longitudinal travel-X 760 mm/(inch)
Cross travel-Y 500 mm/(inch)
Vertical-Z 500 mm/(inch)
Spindle end to table 140-640 (100 - 600) mm/(inch)
Spindle center to column 510 mm/(inch)
Spindle speed (variable frequency motor) 60-6000
(L:60-520)
(H:520-4200)
rpm
Spindle travel 125 mm/(inch)

FMC-B2V(L)


CNC milling machine specification
table size 1370 x 400 mm/(inch)
T-slot 16 x 3 mm/(inch)
Max. table load 700 kgs
longitudinal travel-X 1000 mm/(inch)
Cross travel-Y 500 mm/(inch)
Vertical-Z 500 mm/(inch)
Spindle end to table 140-640 (100 - 600) mm/(inch)
Spindle center to column 510 mm/(inch)
Spindle speed (variable frequency motor) 60-6000
(L:60-520)
(H:520-4200)
rpm
Spindle travel 125 mm/(inch)

FMC-B4V(L)


CNC milling machine specification
table size 1702 x 410 mm/(inch)
T-slot 18 x 4 mm/(inch)
Max. table load 1000 kgs
longitudinal travel-X 1200 mm/(inch)
Cross travel-Y 600 mm/(inch)
Vertical-Z 600 mm/(inch)
Spindle end to table 140-740 mm/(inch)
Spindle center to column 650 mm/(inch)
Spindle speed (variable frequency motor) 60-6000
(L:60-520)
(H:520-4200)
rpm
Spindle travel 140 mm/(inch)

FMC-B6V(L)


CNC milling machine specification
table size 1880 x 410 mm/(inch)
T-slot 18 x 4 mm/(inch)
Max. table load 1200 kgs
longitudinal travel-X 1500 mm/(inch)
Cross travel-Y 650 mm/(inch)
Vertical-Z 600 mm/(inch)
Spindle end to table 140-740 mm/(inch)
Spindle center to column 660 mm/(inch)
Spindle speed (variable frequency motor) 60-6000
(L:60-520)
(H:520-4200)
rpm
Spindle travel 140 mm/(inch)
